Technology

Broadband

Broadband

Broadband

Horizontal transducers

2

2

2

Horz. beam width

  2°

  1.1°

  1.1°

Vertical transducers

1

1

1

Vert. beam width

  5°

  5°

  5°

Profiling range

1-350 m

1-120 m

0.5-35 m

Accuracy

±[0.5% * measured value±2mm/s]

±[0.5% * measured value±2mm/s]

±[0.5% * measured value±2mm/s]

Velocity range

±5m/s (default)

±20m/s (maximum)

±5m/s (default)

±20m/s (maximum)

±5m/s (default)

±20m/s (maximum)

Resolution

1mm/s

1mm/s

1mm/s

Layers

1-256

1-256

1-256

Layer size

1～ 8 m

0.5～4m

0.25～4m

Water level

Range

0.1-20m

0.1-20m

0.1-20m

Accuracy

±0.1%±3mm

±0.1%±3mm

±0.1%±3mm

Built-in sensors

Temperature

Range: -10°～+85°
  Accuracy: ±0.1℃
  Resolution: 0.001℃

Range: -10°～+85°
  Accuracy: ±0.1℃
  Resolution: 0.001℃

Range: -10°～+85°
  Accuracy: ±0.1℃
  Resolution: 0.001℃

Motion

Range: 0～50°;

Accuracy: 0.2°;

Resolution: 0.01°;

Range: 0～50°；

Accuracy: 0.2°；

Resolution: 0.01°;

Range: 0～50°；

Accuracy: 0.2°；

Resolution: 0.01°;

Gyro

Range: 0°~360°；

Accuracy:±0.5°；

Resolution: 0. 01°

Range: 0°~360°；

Accuracy:±0.5°；

Resolution: 0. 01°

Range: 0°~360°；

Accuracy:±0.5°；

Resolution: 0.   01°

Memory

2G

2G

2G

Communication

Standard protocolagreemet

RS-232 or RS-422;

RS-232 or RS-422;

RS-232 or RS-422;

Software

IOARiver

IOARiver

IOARiver

Modbus interface module

Modbus

Modbus

Modbus

Physical

Power supply

10.5v-36v

10.5v-36v

10.5v-36v

Average power consumption

＜10W

＜10W

＜10W

House material

POM (standard) / Aluminum   alloy, titanium alloy (optional)

POM (standard) / Aluminum   alloy, titanium alloy (optional)

POM (standard) / Aluminum   alloy, titanium alloy (optional)

Depth rating

50m(standard),   2000m/6000m(optional)

50m(standard),   2000m/6000m(optional)

50m(standard),   2000m/6000m(optional)

Operation temp.

-5℃ - 55℃

-5℃ - 55℃

-5℃ - 55℃

Storage temp.

-20℃ - 65℃

-20℃ - 65℃

-20℃ - 65℃
